Hemodialysis Water Treatment System
Water treatment plays an important role in hemodialysis treatment. The reverse osmosis water treatment system developed by Molewater ensures a dialysate preparation system of stable quality, maximizes the safety of patients’ lives, and saves resources by minimizing water and energy consumption.
Hemodialysis water purification equipment adopts two-stage reverse osmosis technology, the quality of produced water meets the requirements of YY 0572-2015 Water for Hemodialysis and Related Treatments, American AAMI/ASAIO standards and ISO13959 water for hemodialysis, the produced water total number of bacteria ≤100 CFU/mL, endotoxin<0.25EU/mL.
The dialysis ro water purification machine for hemodialysis produced by our company can be used in conjunction with dialysis machines brand such as Fresenius, Nihon Kohden, B. Braun, Nipro, Baxter, Bellco, Toray, Asahi Kasei,SWS, Jihua, and so on.
Share to
Product Characteristics
- The whole machine is skid-mounted , including pretreatment system, reverse osmosis system, circulation system and disinfection system.
- According to different water source quality, customer can choose single-stage, double-stage reverse osmosis system, ion removal rate ≥ 99%.
- PLC+touch screen intelligent automatic control system, full automatic operation.
- Concentrated water recycling function, the system recovery rate can reach 85%.
- Automatic + manual operation mode. It can realize 1st stage RO and 2nd stage RO two independent working mode to ensure uninterrupted water supply to dialysis machines.
- Adopting direct supply mode between all stages of membrane, purified water directly supply to dialysis machine with full-circulation constant-pressure pipeline, and adopts orbital welding technology to ensure the inner wall of the pipeline is smooth, and all time fresh water for dialysis, effectively avoiding microorganisms super breeding.
- Whole machine is made of sanitary stainless steel, the unique dead-end design of reverse osmosis system, and pipeline Tri-clamp connection, the structure is compact, simple and beautiful.
- Multi-functional monitoring device can realize online monitoring of water quality conductivity, flow rate, pressure and other key parameters.
- Direct supply mode and water storage tank recirculation mode for customer’s choice
- One-key start automated chemical disinfection function and disinfection time record function, pipe network heating disinfection function is optional.
- Pipe network can be supplied with material of UPVC, SUS304, SUS316L and PEX-A material according to customer’s requirement.
Technical Parameters
| Model | Flow capacity | Power | Feed for dialysis machine (sets) |
| MOL-TX-CSA | 200-600L/H | 3.5KW | 1-15 |
| MOL-TX-CSB | 600-1300L/H | 6.0KW | 15-30 |
| MOL-TX-CSC | 1300-2500L/H | 9.0KW | 30-50 |
| MOL-TX-CSD | 2500-4000L/H | 12.0KW | 50-100 |
