Pure Water System
The reverse osmosis pure water system uses tap water and groundwater as raw water, pretreated by quartz sand filter, activated carbon filter, and softener(softener is optional), and then transmitted to the RO reverse osmosis system through a high-pressure pump. After a series of purification treatments, the raw water can remove harmful substances such as particles, colloids, organic impurities, heavy metal ions, bacteria, viruses, heat sources, and 99% of dissolved salts. The desalination rate of the reverse osmosis system can be as high as 97% to 99%, produce water conductivity ≤ 10μs/cm.
Share to
Technical Specification
| Product | Reverse osmosis pure water system |
| Capacity | 0.25T/H-100T/H |
| Material | SS304/FRP |
| Control | PLC+HMI touch screen |
| Produce water quality | Conductivity ≤ 10μs/cm |
| Working flow | Feed water – raw water tank -raw water pump – muti-media filter – activated carbon filter – precision filter – high pressure pump – reverse osmosis system – high pressure pump – reverse osmosis system – pure water tank – pure water pump – water points |
Features
01
Automatic stopwhen there is no water or low pressure or when pure water tank is full, and automatic product water when pure water tank is short of water
02
Automatic control and RO membrane automatic flushing to reduce pollution speed
04
The low-pressure switch protects the high-pressure pump from damaging the pump unit
05
The produced water conductivity meter continuously monitors the quality of produced water
