Purified Water System (PW)

Molewater’s purified water system has the following advantages:

  • Capacity varying from 250LPH to 10,000LPH,
  • Compliance with GMP, Eur, Ph, USP and JP regulatory requirements or site-specific requirements,
  • Sanitary in-line instrumentation to monitor product critical parameters such as conductivity, temperature, hardness, turbidity, PH, TOC, Ozone in water and so on.

Molewater has over 20 years of expertise in designing, manufacturing, and installing pharma water systems and pharmaceutical water system solutions. Serving 1,000+ pharmaceutical plants and hospitals across 80+ countries. Feel free to contact us for your special needs.


Share to

Product Description

Purified water is a critical ingredient and processing aid for many pharmaceutical industries. Solutions are required to comply with defined criteria for conductivity, total organic carbon(TOC) and bacteria.

Molecular water has built a market leading reputation on designing purified water system that work for you, irrespective of the desired grade, capacity or application.

Our core offerings include:

Purified Water System (PW) – a pharmaceutical purified water system ideal for general pharmaceutical processes

PW Storage & Distribution System – ensuring safe, closed-loop circulation

Multi‑Effect Distilled WFI Generator – certified pharmaceutical water treatment plant for generating Water For Injection.

Pure Steam Generation & WFI Distribution Systems – supporting injection-grade water needs.

These systems form a complete purified water generation system in pharmaceutical industry, covering the full lifecycle from generation to delivery. Please no wonder to choose Molewater as your Purified Water System Manufacturer.

Features of Purified RO EDI Water Plant

01 Automated Control System

Equipped with a PLC and HMI interface, the system operates under a fully automatic control mode, ensuring stable performance, minimal manual intervention, and user-friendly operation.

02 Regulatory Compliance

The treated water consistently meets the stringent quality standards of GMP and USP, making it suitable for use in pharmaceutical and healthcare applications.

03 Enhanced Microbial Control

Heat disinfection is applied to both the activated carbon filter and the distribution loop, effectively suppressing microbial growth and maintaining hygienic conditions throughout the system.

04 High-Quality Piping and Welding

All piping connections are completed using orbital welding with double-side molding, resulting in smooth inner surfaces that reduce contamination risks and facilitate easy cleaning.

05 Compact and Modular Design

The system adopts a modular, space-efficient design with a reasonable layout, attractive appearance, and structure optimized for easy daily operation and maintenance.

06 Automatic RO Membrane Cleaning

A self-cleaning procedure is triggered each time the machine starts, helping to maintain RO membrane performance and extend service life by preventing fouling and scaling.

Two stage RO high pressure pump with low and high pressure protection switch, avoid the pump from dry running

Meters and sensors to online monitor the water quality and flow

Electric control box with all necessary electric components, PLC module, relays, VFD to realize automatic operation of the whole system

PW System Specification

Feeding water quality Drinking Water /City water /Tap water
Water capacity 250 to 10,000LPH
PretreatmentMultimedia, active carbon, softener filter
SterilizationOzone sterilizer / Hot water over 85 degrees / UV Lamp
RO membraneDOW USA
EDI brandIonpure brand / Winviews
 Water pumpGrundfos or CNP
Online monitoringConductivity, temperature, pressure, TOC, flow rate, PH etc.
Meter brandsChinese & burket ,Jumo & others
ControlAutomatic with PLC, Siemens
WeldingAutomatic Orbit welding
MaterialsSS304 / SS316L
Other attached productsDistribution system with Loop
